Special Function
88爱彩网 *Stack material fast in good order.
*PLC intelligent control, double axis uses servo motor, which can be precisely controlled.
*The machine runs steadily, and is easy to operate.
88爱彩网 *Automatic detection system, stable performance.
88爱彩网 *The machine can be used with panel cutter with high efficiency.
88爱彩网
Application
Used for stacking the quilted fabric after cutting.
88爱彩网
功能参数/Technical Details
|
外型尺寸 (长X宽X高）Size |
3070*3480*2350mm |
|
叠料速度 Speed |
5pcs/min |
|
适合面料外型尺寸Applicable for material width |
≤2400mm |
|
最大可叠高度 Applicable for material height |
1850mm |
|
重 量 Weight |
500KG |
|
总功率 Power |
2KW |
|
电源 Voltage |
380V 50HZ |
